TBS-50 Batch Tunnel Washer
High-Volume, Energy-Efficient Batch Washing for Industrial Laundries
The TBS-50 Batch Tunnel Washer is the heart of the Girbau Industrial Continuous Batch Washing System, built for high-volume commercial and industrial laundries. Available with 5–12 wash modules (110-pound capacity each), it processes up to 3,000 pounds of laundry per hour while reducing water, energy, chemical and labor costs.
Designed for maximum efficiency, the TBS-50 combines a durable mono-block construction with advanced programmable controls for consistent wash quality and reliable performance. Top-transfer technology minimizes tangling and prevents bath mixing, while load-based chemical dosing and an energy recovery system help lower operating costs. Steam injection up to 176°F supports hygienic laundering, and remote monitoring simplifies service and maintenance.
Special Features:
- A Modular design with 5–12 wash modules, each with 110-lb. capacity
- Top-transfer technology minimizes tangling and eliminates bath mixing
- Chemical dosing tailored to the actual load weight so that results are optimized
- Per-module control of wash settings: temperature, cycles, inversion and dosing
- Compatibility with third-party systems and components for added flexibility
- Cuts water use by 50–60 percent and chemical use by up to 40 percent
- Energy recovery system reuses rinse water up to 3 times which saves costs
- Remote monitoring, diagnostics and support
- Fits into a standard container for reduced shipping and faster installation
What Makes the TBS-50 a Great Fit for Industrial Laundries?
Dual Drum Technology for Maximum Control
The inner and outer drum construction of every module allows for precise bath control, programmability and complete isolation between loads. Each module can perform an independent bath exchange so that it matches specific laundering needs.
Advanced Programmability
Customize every phase of the wash cycle with 99 programmable settings across 999 client profiles. For instance, configure parameters like:
- Water temperature and levels.
- Cycle duration and mechanical action.
- Chemical dosing.
- Drum inversion and bath partitioning.
Top-Transfer System: No Cross-Contamination
Unlike bottom-transfer models, the TBS-50 uses a top-transfer design, which moves laundry without mixing water between modules. Sensors verify conditions before transfer, ensuring smooth transitions.
Disinfection & Traceability
Steam injectors and intermediate filter tanks prevent particles from the rinse cycle from being recovered or reused in the wash process. Wash cycles are conducted at temperatures required for verified disinfection and hygiene compliance. In addition, the system provides full traceability for each load, including temperature logs, chemical dosing and cycle times.
Water-Saving Innovation
Smart water reuse strategies drastically cut water usage. Fresh rinse water is applied to clean linens, while reclaimed rinse water is reused for initial wash phases, thus optimizing both efficiency and sustainability.
Streamlined Installation & Maintenance
Shipped fully assembled in a single container, the TBS-50 cuts shipping and setup costs. Its compact, dual-drum design delivers more power and quality in less space than bulky, single-drum alternatives. As a result, installation is faster and easier.
Total Control with the Batch Management Tool
Get full visibility and control over your entire wash process from a single intuitive touchscreen interface:
- Monitor temperatures, weights, dosing and cycle status in real time.
- Customize up to 99 wash programs.
- Track loads by customer for precise batch management and reporting.
